Collected Illustrations of the Three Realms: Instruments, Volume 9

The Skein Frame and the Spinning Spindle

The Skein Frame original: 綛車 (rènchē) and the Spinning Spindle original: 旋椎 (xuánzhuī) are fundamental tools in the traditional Chinese textile workshop, used for the preparation and refinement of thread.

The Skein Frame Skein FrameAlso known as a yarn winder or reel; it is a wooden apparatus used to wind finished thread into organized loops called "skeins" or "hanks." is a structural frame designed to catch thread as it is pulled from a spindle or bobbin. By winding the thread onto this frame, the weaver can create uniform bundles that are easy to transport, dye, or store without the thread becoming tangled.

The Spinning Spindle Spinning SpindleA weighted tool, often called a drop spindle, used to twist raw fibers (such as silk, hemp, or cotton) into a continuous, strong thread through the use of centrifugal force. is a simpler, more ancient tool. It typically consists of a central shaft and a weighted whorl at the bottom. The spinner twists the fibers and drops the spindle, letting its rotation provide the necessary "twist" to turn loose fiber into durable yarn.

In the accompanying illustration, the Skein Frame is shown on the right as a sturdy frame for winding, while the Spinning Spindle appears on the left, depicted as a weighted tool for manual spinning. Together, these instruments represent the bridge between raw agricultural materials and the finished woven cloth.
